Machine & Instruments
Presently we are manufacturing & supplying highly precision machined components some of our Machine & Instruments Infrastructure are follows:
List of Machines
_____________________________
| S. No. | MACHINE | MAKE | CAPACITY | QUANTITY |
|---|---|---|---|---|
| 1. | CNC Lathe Model-LT-2 | Ace Designers | D240X380L | 3 |
| 2. | CNC Lathe Jobber-XL | Ace Designers | D240X350L | 2 |
| 3. | VMC MCV-400 | Ace Designers | 1 | |
| 4. | VMC MCV-450 | Ace Designers | 1 | |
| 5. | Milling M/C (M1TR) | Taiwan | 3 | 1 |
| 6. | Milling M/C (Universal) | RS Hydrolucs | 18''x60'' | 1 |
| 7. | Milling M/C (Vertical) | RS Hydrolucs | 18''x60'' | 2 |
| 8. | Lathe | Everest | 6' | 13 |
| 9. | Cylindrical Grinder | Smithsons | 600MM | 1 |
| 10. | Surface Grinder | Ramanna Enterprises | 9''x18'' | 1 |
| 11. | Power Hacksaw | Lawson | 8'' | 1 |
| 12. | Drilling Machine | Machless | 5/8'' & 1'' | 2 |
| 13. | Tapping Machine | JMT | 6MM | 1 |
| 14. | D.G. Set | Kirlosker | 40 KVA & 60 KVA | 2 |
List of Instruments
_____________________________
| S. No. | INSTRUMENT | MAKE | SPECIFICATION | QUANTITY |
|---|---|---|---|---|
| 1. | Micrometer | Mitutoyo | 0-25mm | 3 |
| 2. | do | do | 25-50mm | 2 |
| 3. | do | do | 50-75mm | 2 |
| 4. | do | do | 75-100mm | 2 |
| 5. | do | do | 100-125mm | 2 |
| 6. | do | do | 125-150mm | 2 |
| 7. | Vernier | Mitutoyo (Digital) | 8" | 1 |
| 8. | Vernier | Mitutoyo (Dial) | 8" | 4 |
| 9. | Height Gauge | Mitutoyo | 12' | 2 |
| 10. | Bore Gauge | Mitutoyo | 8-150mm | 3 |
| 11. | Depth Micrometer | Mitutoyo | 0-75mm | 2 |
| 12. | Level Protector | Mitutoyo | - | 1 |
| 13. | Surface Plate | Begson | 2'x2' | 1 |
| 14. | Surface Finish Tester | Mitutoyo | 1 |
